Helix C 6B
6.5" (16.5cm) Mellemtoner
C921600
SPAR 0%
Helix C 6B
6.5" (16.5cm) Mellemtoner
- DETTE ER ET OUTLET-PRODUKT!
- Kan have beskadiget emballage! Derfor den lave pris!
- Varen er 100% ny og ubeskadiget!
- 30 dages fuld returret og 2 års garanti
- Kan KUN bestilles her på outlet.carsound.dk
- BEGRÆNSET ANTAL og Først-til-mølle
2999 DKK
1.559,48
PR. SÆT
excl. moms
VAREN ER DESVÆRRE UDSOLGT
Kontakt Kundeservice her for evt. alternativ
- DETTE ER ET OUTLET-PRODUKT!
- Kan have beskadiget emballage! Derfor den lave pris!
- Varen er 100% ny og ubeskadiget!
- 30 dages fuld returret og 2 års garanti
- Kan KUN bestilles her på outlet.carsound.dk
- BEGRÆNSET ANTAL og Først-til-mølle
x
Nærmere beskrivelse på dansk følger snarest...
These reference speakers in our C-series raise the bar to a new level of fantastic sound quality. The legendary sisal woofer cones are equipped with an additional structural damping layer made of an elastomer, which again improves the acoustic properties of the driver. The tweeter enclosure also underwent a complete overhaul. Anyone who wants to operate these loudspeakers as fully active speakers (e.g. using our new digital signal processors) can put together the system of their choice by combining the individual components.
Features
High-end mid-woofer with sturdy aluminum diecast basket
Mid-woofer cone with scooped, long-fibered sisal with additional elastomer structural damping
Virtually compression-free conversion of the amplifier power into sound pressure
Lowest manufacturing tolerances and exclusive use of selected materials
Grille included
Technical data
Power RMS / max. P 150 / 300 Watts
Impedance Z 4 Ω
DC resistance Re 3.4 Ω
Resonance frequency Fs 54 Hz
Mechanical Q factor Qms 11.1
Electrical Q factor Qes 0.55
Total Q factor Qts 0.53
Compliance Cms 490 µm/N
Equivalent air volume Vas 12.4 L
Force factor B*I 6.1 Tm
Efficiency 1 W / 1 m SPL 88 dB
Cone area Sd 135 cm²
Moving mass Mms 17.8 g
Cone material Sisal with elastomer structural damping
Mechanical resistance Rms 0.54 kg/s
Voice coil diameter ø 37 mm
Voice coil winding height 12 mm
Max. linear excursion Xmax +/- 3 mm
Outer diameter ø 166 mm / 6.54"
Installation diameter ø 145 mm / 5.71"
Installation depth 67 mm / 2.64"
Recommended enclosure volumes
Sealed box
Net volume 8 L
Lower limiting frequency (-3dB) 68 Hz
Vented box
Net volume 15 L
Port diameter ø 60 mm / 2.36"
Port area 28 cm²
Port length 16 cm / 6.30"
Port tuning frequency Fb 49 Hz
Lower limiting frequency (-3dB) 52 Hz
Scope of delivery
2 x High-end mid-woofer HELIX C 6B
2 x Mounting ring
2 x Grille
